4.3 Power Supply Ratings
52
 PLS62T-W_HID_v01 2018-06-20
Confidential / Prelimenary
Page 46 of 91
I
PLUS
Peak supply current
(during 577µs transmis-
sion slot every 4.6ms)
Power control
level for Pout max
(850/900MHz)
@8V 1130 mA
@30V 270
@57V ---
Power control
level for Pout max
(1800/1900MHz)
@8V 820 mA
@30V 200
@57V ---
Average UMTS supply
current (average time 3
min.)
IDLE mode @8V 79 mA
@30V 12
@57V ---
UMTS DATA
(Band I; 23dBm)
@8V 410 mA
@30V 115
@57V ---
UMTS DATA
Band II; 23dBm
@8V 450 mA
@30V 125
@57V ---
UMTS DATA
Band V/VI; 23dBm
@8V 415 mA
@30V 115
@57V ---
UMTS DATA
Band VIII; 23dBm
@8V 410 mA
@30V 115
@57V ---
HSPA DATA
(Band I; 23dBm)
@8V 415 mA
@30V 115
@57V ---
HSPA DATA
Band II; 23dBm
@8V 450 mA
@30V 125
@57V ---
HSPA DATA
Band V/VI; 23dBm
@8V 415 mA
@30V 115
@57V ---
HSPA DATA
Band VIII; 23dBm
@8V 410 mA
@30V 115
@57V ---
Table 22: Power supply specifications
Para-
meter
Description Conditions Unit
PLS62T-W
USB
