geminox FCX 22 C User Manual

- 5 -
II - TECHNICAL SPECIFICATIONS
1 - CHARACTERISTICS
* A 3m horizontal or vertical concentric flue connec-
tion increases in efficiency by about 2 %.
Model
FCX 22 C FCX 30 C
Certification following efficiency directive 92/42/CEE CE1312AS036R
Connection B
23
/B
23p
/C
13
/C
33
Power output
maxi kW 22,3 30,5
Heat flow maxi kW 23,8 31,5
Efficiency (in B
23
)*
60/80 °C % 96,3 96,7
Part load efficiency (30 %) (B
23
)*
% 99,0 99,8
Combustion product temperature (B
23
)
maxi °C 90,0 95,5
Flow rate of combustion products (0 °C, 1013 mbar)
g/s 11 15
Permitted back pressure maxi Pa 30 30
Air flow required for combustion (0°C, 1013 mbar)
m
3
/h
29,1 39,4
Combustion chamber length
mm 228 239
Ø Combustion chamber
mm 294 350
Combustion chamber volume
dm
3
15 23
Volume of combustion products circuit
dm
3
50 52,5
∆P flue
Pa 25
Heating service pressure
maxi bar 3
Heating circuit water temperature
mini/maxi °C 10/80
Boiler temperature maxi °C 80
Water overheating safety thermostat
°C 110
Flue overheating safety thermostat
°C 120
Boiler water capacity litre 16 25
Primary water flow
60/80 °C m
3
/h 0,96 1,3
∆P water (at nominal flow)
mCE 1,0 1,8
Heatlosses ∆T 30 K
∆T 50 K
W
W
137
260
144
273
Service consumption coefficient (∆T 50 K) %1,3
Total capacity of expansion vessel litre 812
Useful capacity (for static height of 5m) litre 57,5
Power consumption (Continuous working with heating circulating
pump at maximum speed)
W 277 297
Power consumption with heating circulating pump
Speed 1
Speed 2
Speed 3
W
W
W
40
60
88
Power absorbed (with burner, without circulator) W 189 209
Power supply / Protection index
230 V - 50 Hz / IP x 0D
Class of electrical insulation 1
Absorbed intensity maxi A 1,2 1,3
Weight without packaging kg 134 158
Weight with packaging kg 148 168
