13 Table for changes to the factory settings
Config. level Display Function P1 P2 P3 P4 Factory setting
1 Service
New Code: 1 Release the lowest priority X X X 0
New Code: 2 Release the medium priority X X X 0
New Code: 3 Release the top priority X X X 0
Warnings Display warnings during operation ON
Errors Display errors during operation ON
Config. level Display Function P1 P2 P3 P4 Factory setting
2 SetBasics
Setpoint Type of set value signal 4-20 mA
D.Refresh Time for display refresh X X X 0.5 s
Systemmode Type of operator interface X X X Classic
DLight Setting the display lighting OnKey
DLightTime
Time for switching off display lighting
during adjustment [OnKey]
5 min
HelpLanguage Text language D
HelpText Display the help text ON
Config. level Display Function P1 P2 P3 P4 Factory setting
3 SetFunction
Prop Gain P amplification of the positioner X.X
Deriv Time
Decay time of the D component of the
positioner
1.00 s
Min Pos
Seal adjuster = lower position of control
range
0.0 %
Max Pos
Stroke limiter = upper position of control
range
100 %
CloseTight Lower close tight function no
DeadBand Permissible system deviation 1.0 %
Alarm Functn
Determines the function of the alarm
output
OFF
Level Alarm 1 Switch point of alarm 1 10.0 %
Level Alarm 2 Switch point of alarm 2 90.0 %
Error Functn
Determines the function of the error
message output (ERROR)
ERROR + RANGE
Error Time
Valve travel time monitoring ( Error
message output)
AUTO
Error Level
Maximum system deviation ( Error
message output)
AUTO
Range Functn Range monitoring of set value input < 4 mA or > 20 mA
Analog Out
Determines the function of the actual
value output
0-10 V (4-20 mA)
Out min
Valve position on actual value output
signal 0 V (0/4 mA)
0.0 %
Out max
Valve position on actual value output
signal 10 V (20 mA)
100.0 %
