Pos
Config. level Display Function P1 P2 P3 P4 Factory setting
4 SetCalibration
X-DIR
Direction of X display and actual value
output
RISE
Setp Dir Direction of set value NORMAL
Setp Ramp Ramp function - set value 0 s
Split Start Split range (set value range) start 0.0 %
Split End Split range (set value range) end 100 %
Setp Functn
Defines the function of the control
characteristic
Linear
W 0 % 2.0
W 10 % 3 .0
W 20 % 4.4
W 30 % 6.5
W 40 % 9.6
W 50 % 14.1
W 60 % 20.9
W 70 % 30.9
W 80 % 45.7
W 90 % 67.6
W 100 % 100
14 Disposal
l All parts must be disposed of according to
relevant local or national disposal regulations /
environmental protection laws.
l Pay attention to adhered residual material and
gas diffusion from penetrated media.
15 Returns
l
Clean the positioner.
l Request a goods return declaration form from GEMÜ.
l Returns must be made with a completed declaration of
return.
If not completed, GEMÜ cannot process
7 credits or
7 repair work
but will dispose of the goods at the operator’s expense.
Note for returns:
Legal regulations for the protection of the environment
and personnel require that the completed and signed
goods return declaration is included with the dispatch
documents. Returned goods can be processed only
when this declaration is completed.
16 Information
Note on staff training:
Please contact us at the address on the last page for
staff training information.
Should there be any doubts or misunderstandings in the
preceding text, the German version of this document is the
authoritative document!
