5
Mounting Requirements
Bearing
You can choose the potable or wall mounting method according to your needs.
Wall mounting can substantially save the space.
If you choose portable mounting, use the mounting rack or support. If you want to
use a self-made mounting rack, the bearing capacity of the rack should be at least
four times of the actual weight of the display. The bearing capacity of the mounting
support must be at least four times of the actual weight of the display to ensure
steadiness of the interactive panel.
When you choose wall mounting, the bearing capacity of the mounting surface
must be at least four times of the weight of the display. When the mounting surface
is a wall or ceiling of a building, the wall must be built with solid bricks, concrete or
materials of equal intensity. If you need to mount the display on a loose surface
such as an old brick wall, wood plank wall, solid brick wall, metal or non-metal
structure wall, or a wall with a thick decoration layer, take necessary consolidating
measures to ensure that the display is steadily mounted.
Ventilation
Ventilation Requirements
Distance to the mounting surface (cm)
Nominal Power Left and
right sides
Top Bottom Back
Larger than 100W 10 20 20 10
Note: If the product is mounted inside a wall or a cabinet, in addition to the above
mentioned requirements, the area of ventilation holes at the bottom, top and two
sides must be at least 50% of the sealing surface to ensure proper ventilation.
