Setup and Operation
12 Installation and User’s Manual for Wi-Fi Module
9. See Figure 3-15. Once a successful
connection is made to the network, the
controller display will show the
homeowner’s network name.
Figure 3-15. Successful Connection
10. Return to the generator controller and
continue generator setup through the
Install Wizard.
11. Verify controller firmware is up to date by
selecting Update From: WiFi. Any
updates will be automatically loaded.
This completes the connection process.
Proceed to Download Mobile Link and
Complete Registration.
Unsuccessful Network Connection
If the connection attempt fails:
• The “You’re Connected!” page will not
appear.
•See Figure 3-16. The controller displays
“Setup Failed...Retry?”
Figure 3-16. Wi-Fi Setup Failure Screen
Proceed to Retry Network Connection if either
condition exists.
