Models FL3100/3101
35
R - indicates Read Only Access R/W - indicates Read/Write Access
Master
Reg I/O Refer
Parameter Function Type Scale Access To Addr Addr Section
Comm 1 Only Total # of Comm 1 Only Value 8-Bit R 0024 40037 7.7.24
Total Receive Receive Errors
Errors
Comm 1 & 2 Total # of RXD CRC Lo Value 8-Bit R 0025 40038 7.7.25
RXD CRC Lo Errors (Comm 1 & 2)
Errors
Comm 1 & 2 Total # of RXD CRC Hi Value 8-Bit R 0026 40039 7.7.26
RXD CRC Hi Errors (Comm 1 & 2)
Errors
Comm 1 Only Total # of Overrun Errors Value 8-Bit R 1027 40040 7.7.27
Overrun Errors (Comm 1 Only)
Comm 1 Only
Total # of Noise Flags Value 8-Bit R 0028 40041 7.7.28
Noise Flag Errors (Comm 1 Only)
Errors
Comm 1 & 2 Total # of Framing Value 8-Bit R 0029 40042 7.7.29
Framing Errors Errors (Comm 1 & 2)
Comm 1 or 2 Indicates Comm 1 or 2
Value 8-Bit R 002A 40043 7.7.30
Message Interval Message Interval in Milli-
seconds
Comm 2 Only Total # of Comm 2 Only Value 8-Bit R 002B 40044 7.7.31
Total Receive
Errors
Receive Errors
Comm 1 Only Total # of Serial Comm Value 8-Bit R 002C 40045 7.7.32
SCI Interrupt Interface Errors (Comm 1
Errors Only)
Comm 1 & 2
Errors
Clear All Comm 1 & 2
Errors
Bit
1-Bit R/W 002D 40046 7.7.33
Not Used 002E 40047
Comm 2 Address Unit Address (Comm 2) Decimal (1-247) R/W 002F 40048 7.7.34
Hex (01-F7)
Comm 2 Baud Indicates present Baud Rate Value (0-3) R/W 0030 40049 7.7.35
Rate (Comm 2)
(2400, 4800, 9600, 19.2K)
Comm 2 Data Indicates present Data Value (0-3) R/W 0031 40050 7.7.36
Format Format (Comm 2)
(8N-1, 8E-1, 8O-1, 8N-2)
