Models FL3100/3101
36
8.7 FL3100, FL3101 Operational Mode Command Register
Details
8.7.1 Analog
A read returns a value, which is proportional to the 0-20mA output current. The
current is based on a 16-bit value. The master scaling is 0-65535 decimal, which
corresponds to the FL3100, FL3101 scaling which is 0-20mA.
8.7.2 Mode
A read returns the fire status mode of the FL3100, FL3101.
Mode Decimal Value
Power-up Delay 1
Warn Non-latching Only 2
Warn & Alarm Non-Latching 3
Warn Latching Only 4
Alarm Latching Only 5
Warn & Alarm Latching 6
Ready State (No Fire) 7
UV Only Fire (FL3100 Model Only) 8
IR Only Fire (FL3100 Model Only) 9
Alarm Test 10
COPM Fault Detected 11
8.7.3 Status/Error
A read returns the errors that are occurring at the present time which are
indicated by bit position.
Byte Function Bit
Position
Low EPROM Checksum 8
EEPROM Checksum 7
RAM Test 6
Low Line Voltage Check 5
UV COPM 4
IR COPM 3
Not Used 2
Not Used 1
High Reset Line Shorted 8
UV 10 Minute 7
Not Used 6-1
8.7.4 UV/IR Only
A read indicates the detection of UV Only or IR Only when using the UV/IR
Model FL3100.
UV Only Detected= 01 (Lo Data Byte)
IR Only Detected = 02 (Lo Data Byte)
High Data Byte Not Used.
