Manual
Regen/Esc. Key
Press at any phase during manual regeneration to advance to the next phase or press during programming to exit
to the home screen without modifying the current highlighted option.
Up and Down Arrows
and buttons are used to scroll through the various basic programming options as well as adjust values.
Basic Programming
Allows you to adjust the time values for each phase. To enter basic programming, follow the directions below.
1. When the icon is on, press and hold both and for 3 seconds to unlock the keypad.
2. Press to enter the main menu; press or to highlight each option.
3. Press to enter highlighted option.
4. Press or to adjust the value.
5. Press to accept changes.
6. Press to exit back to service status.
Advanced Programming (Dealer use ONLY)
This area is preprogrammed rammed by the dealer for your specific water. Any adjustments made in
advanced programming can cause your system to not function properly and even void warranty coverage.
1. Plug in the Genesis Upflow. Immediately press
in sequence to enter into the advanced setting.
2. Press or to select the menu item to be changed.
3. Press to return to the previous menu.
If valve locks while programming, unplug power supply and repeat step above.
4. Press to enter the main menu; press or to highlight each option.
5. Press to enter highlighted option.
6. Press or to adjust the value.
7. Press to accept changes.
8. Press to advance to service status.
Genesis Upflow Valves & Systems Service Manual
