Programming: Modes A-03
Parameter Unit Default Description
Review Company Info Displays current programmed company information.
Language * English
Set Company Info * Set company information for display. Three lines available for input
Set Time of Day 24-hr. Clock Set current time of day. 24-hour clock format.
Set Date Set current month, day, and year. XX/XX/20XX
Set Program Type *
Interlock / Alternate Interlock
Interlock
Used as a stand-alone installation and twin demand in conjunction with
No Hard Water version of the Genesis Upflow.
Set Regen Cycles * 1, 2, 3 2
Recommended setting to Sequence 2. See Pages 7-8. Service → Backwash →
Brine & Slow Rinse → Back Wash → Fast Rinse → Brine Refill.
Set Clear Data * Close/Open Close
Skip during initial set-up. Clears all stored memory and restores default
settings. Close = Data saved Open = Reset data
Set Regen Mode: A-01-A-07 * A-03 A-03 Intelligent Meter Delayed.
Set Total Capacity Grains
Preset for you by dealer.
Set Water Hardness
Grains per
Gallon (gpg)
10
Total water hardness of incoming water supply. Amount varies per location. It
is highly recommended to have tested for correct function/performance.
Set Number of People 4 The number of people in the residence
Set Regen Time 24-hr. Clock 02:00 The time of day the system will regenerate when it reaches system capacity.
Set Backwash Time Min. 0 Set to 0 (zero) when using Sequence 2 as a softener install.
Set B.S.R. Time Min. 60 Brine Slow Rinse Stage of Regeneration.
Set Secondary B.W.T. (Backwash Time) Min. 10
Set Fast Rinse Time Min. 10
Set B.R. Time (Brine Refill) Min:Sec
Refill time is calculated and set by your dealer for standard efficiency.
Do not change unless consulting with your dealer.
Max Days for Regeneration Days 30
A regeneration is forced every 14 days if no water has been used.
Signal Output Mode b-01 (02) * b-01 Used for external device. b-01. Disregard for standard installation.
Set Service Alarm * Days 730
Alarm rings to prompt a service call. Occurs at the number of days set at 8pm
for 2 minutes. Display changes to prompt the homeowner to call their dealer.
Daily Usage Log Gal. Shows the gallons used each day for the last 7 days.
Daily Peak Usage Gal. Shows the highest gallon usage day for the last 7 days.
Weekly Usage Log Gal. Shows the gallons used each week for the last 52 weeks.
Weekly Peak Usage Gal. Shows the highest gallon usage week for the last 52 weeks.
Monthly Usage Log Gal. Shows the gallons used each month for the last 12 months.
Monthly Peak Usage Gal. Shows the highest gallon usage month for the last 12 months.
Review Regen Times Displays the number of times the valve has regenerated independently.
Review Software Ver.
Shows current software version of Genesis Upflow valve.
Above parameters are located in standard program settings menu. (*) Denotes parameters located in advanced program settings menu.
Genesis Upflow Valves & Systems Service Manual
