5. Valve Installation
Unit Location
• The filter or softener should be located close to a floor drain away from direct sunlight and any heat
sources.
• Protect equipment from direct sunlight and precipitation exposure.
• Install equipment in a location safe from unauthorized access or vandalism.
• Ensure that the unit is installed with enough space for operation and maintenance.
• The installation surface should be clean and level.
• Install the unit in an environment which minimizes consumer risk of loss in the event of malfunction.
• Discount Water Softeners offers many different products for many different applications, for both
indoor and outdoor environments. If you are not 100% sure the equipment purchased is suitable for the
installation application or environment, please check with a Discount Water Softener representative, or
your local equipment provider, to ensure the proper equipment is selected. Equipment installed in
inappropriate applications or environments are not covered by warranty.
• Brine tank should be located close to the control valve. Distance should not exceed 20 linear feet.
Plumbing and Mechanical Setup
If the water outlet or water tank is installed higher than control valve, or parallel interlock system with multi-
outlets, a liquid level controller must be installed in the brine tank. If not, the water outlet or source tank will
flow backwards into brine tank during backwashes.
If making a soldered copper installation, all sweat soldering should be done before connecting pipes to the valve.
Torch heat will damage plastic parts.
When turning threaded pipe fittings onto plastic fitting, take precaution not to cross thread or over tighten.
