2. Product Features and Applications
Primary Applications
Recommended for commercial and residential softening or demineralization water treatment systems.
• Softening System
• Iron Removal System
• Ion Exchange Equipment
• Boiler Softening Water Treatment
• RO Pre-treatment
Product Characteristics
Mechanical Components
The Genesis Upflow uses internal ceramic discs which are corrosion and abrasion resistant to form a hermetic seal.
Rotation of the upper disc aligns to the corresponding lower disc ports for Service, Backwash, Brine & Slow Rinse, Brine
Refill and Fast Rinse modes.
Hard Water/No Hard Water Bypass
Up-flow regeneration with no hard water and hard water bypass options. This valve operates as a hard water bypass.
Excellent Flow Rate: 16 GPM to 22 GPM @ 15psi drop.
365-Day Usage Memory
Manual / Delayed Regeneration
Pressing at any time results in an immediate manual regeneration.
Pressing and holding for 3 seconds, when system is locked, results in a delayed regeneration at the preselected time.
Extended Power Outage Indicator
If outage exceeds 3 days, the time of day indicator “” will flash 12:12. The current time of day needs to be re-set. All
other set parameters remain stored in memory. The valve will resume to operate from the point of the power outage.
Three Regeneration Sequences
Lockout Function
Keypad will lock after 5 minutes without use. To access the parameter changes press and hold and
simultaneously for 3 seconds to unlock.
Genesis Upflow Valves & Systems Service Manual
