Item No. Description Qty. Item No. Description Qty.
1 Injector Cover 1 38 Wire for Locating Board 1
2 Screw, Cross 2 39 Control Board 1
3 O-ring 1 40 Weather Cover 1
4 Nozzle 1 41 Dust Cover 1
5 O-ring 1 42 Screw, Cross 1
6 Throat 1 43 Gear 1
7 Filter Screen 1 44 Screw, Cross 4
8 Screw, Cross 1 45 Locating Board 1
9 Injector Body 1 46 O-ring 2
10 O-ring 2 47 Dust Cover 1
11 O-ring 2 48 Screw, Cross 1
12 O-ring 1 49 Washer 1
13 Screw, Cross 3 50 Spring Washer 1
14 O-ring 1 51 Pick 1
15 Valve Body 1 52 Screw, Cross 4
16 Screw, Cross 2 53 Spring Washer 4
17 Motor 1 54 Control Board 1
18 Screw, Cross 4 55 Seal Ring 2
19 Seal Ring 1 56 Fitting Nut 1
20 Motor 1 57 O-ring 2
21 Fixed Disc 1 58 Anti-friction Washer 1
22 Screw, Cross 4 59 Shaft 1
23 Moving Disc 1 60 Moving Disc 1
24 Small Gear 1 61 Fixed Disc 1
25 Pin 1 62 Seal Ring 1
26 Moving Seal Ring 1 63 Tube 1
27 Shaft 1 64 Hexagonal Nut 1
28 Anti-friction Washer 1 65 Net 1
29 O-ring 2 66 Connector 1
30 Fitting Nut 1 67 Articulated Nut 1
31 Label 1 68 O-ring 1
32 Control Box 1 69 Connector 1
33 Display Board 1 70 Brine Line Flow Control 1
34 Wire for Display Board 1 71 O-ring 1
35 Wire for Power 1 72 Drain Line Flow Control 1
36 Probe Wire 1 73 Clip 1
37 Cable Clip 2
Genesis Upflow Valves & Systems Service Manual
