Genevac HT-8 & HT-12 Series II Evaporating Systems
Page 52 of 64 04-4541 Issue 1-9 – June 2008
9 Technical data HT-8 HT-12
Mechanical data
Max rotor speed 1300 Low Speed 1300 Low Speed
1750 High Speed 1750 High Speed
1800 Dri-Pure 1800 Dri-Pure
Max Force 300-500G 300-500G
Drive system Direct Direct
Operation imbalance 85g 85g
Max load 8 x 1.5 kg @ 500G 12 x 1.5 kg @ 500G
IR lamps number 4 6
Weight 153 kg 180 kg
Condenser
Condenser temperature
Minimum -45°C -45°C
Maximum +60°C +60°C
Vacuum condenser capacity 3.0 litres 3.0 litres
Exhaust condenser capacity 1.5 litres 1.5 litres
Condenser level detector No No
Rapid defrost Yes Yes
Condenser chamber 316 Stainless steel 316 Stainless steel
Condenser drain valve Stainless steel/PTFE Stainless steel/PTFE
Vacuum system
Pressure display/resolution 0 -1000 mbar 0 -1000 mbar
Vacuum control 0 -1000 mbar 0 -1000 mbar
Dri-Pure Yes Yes
Auto vacuum vent valve Yes Yes
Ultimate system vacuum 0.4 mbar 0.4 mbar
Vacuum pump - Scroll
Weight 28 Kg 28 Kg
Maximum vacuum 0.15 mbar (50Hz) 0.15 mbar (50Hz)
0.12 mbar (60Hz) 0.12 mbar (60Hz)
Flow rate 3.6 m
3
h
-1
3.6 m
3
h
-1
Vacuum pump - CVP
Weight 52 Kg 52 Kg
Maximum vacuum 0.15 mbar 0.15 mbar
Flow rate 3.6 m
3
h
-1
3.6 m
3
h
-1
Dimensions
Evaporator (W x D x H) 562 x 700 x 660 mm 562 x 700 x 828 mm
Condenser (W x D x H) 515 x 590 x 425 mm 515 x 590 x 425 mm
Scroll Pump (W x D x H) 530 x 305 x 398 mm 530 x 305 x 398 mm
CVP Pump (W x D x H) 540 x 290 x 405 mm 540 x 290 x 405 mm
