Required Programming
3
REMOTES / New Intellicode 2 Openers
NOTE: The following instructions are for the remote control
transmitters (“Remotes”) provided with this opener. This Remote is
preset for use with the Intellicode 2 Access Security System. Refer to
page 14 for additional information on Intellicode 1 and 2 Remotes and
how to switch from Intellicode 2 to Intellicode 1. See page 14
for programming instructions using Intellicode 1 Remotes.
NOTE: You have 30 seconds to execute each step. If you see two
flashing red LEDs on the Powerhead, you have run out of time and
must go back to the beginning of the step and start over. You can
restart as many times as necessary to complete each step.
NOTE: Each button on each Remote must be programmed separately,
following these steps.
NOTE: Do NOT hold Remote too close to the Powerhead when
programming Remote buttons.
(continued next page)
PROGRAM
–
+
HOLD
2 seconds
HOLD
2 seconds
14
Press and hold the Program Set button (the round
LED turns blue).
PROGRAM
–
+
15
Release the Program Set button (the long LED
begins flashing purple).
PROGRAM
SET
–
+
17
Press and release the button you have choosen
on the Remote (long LED comes on purple).
PUL
16
Remove protective film for battery from remote.
10
G999-393 Manual-ScrewBeltChain-EN indd 10 7/13/12 10 17 AM
