Operator's Manual Third Edition • First Printing

Inspections

34 ZX-135/70 Part No. 1272823GT

Test the Operating Envelope

27 Press the LCD screen

control buttons shown until

PRI BOOM ANGLE TO

GRAVITY is displayed.

28 Raise the primary boom and observe the LCD

screen.

Result: The primary boom should raise and the

LCD screen should display the primary boom

angle in degrees.

29 Lower the primary boom.

30 Simultaneously press the

2 LCD screen control

buttons shown to activate

status mode.

31 Press the LCD screen

control buttons shown until

SEC BOOM ANGLE is

displayed.

32 Press and hold the secondary boom up/extend

button.

Result: The secondary boom should raise and

the LCD screen should display the secondary

boom angle in degrees.

The secondary boom should raise and then

extend. The secondary boom should not

extend until it is fully raised.

33 Press and hold the secondary boom

down/retract button.

Result: The secondary boom should fully

retract and then lower. The secondary boom

should not lower unless it is fully retracted.
