Genie ZX-135/70 with Jib-Extend User Manual

Third Edition • First Printing Operator's Manual
Inspections
Part No. 1272823GT ZX-135/70 35
At the Platform Controls
Test Emergency Stop
34 Turn the key switch to platform control.
35 Push in the platform red Emergency Stop
button to the off position.
Result: The engine should shut off and no
functions should operate.
36 Pull out the red Emergency Stop button and
restart the engine.
Test the Horn
37 Press the horn button.
Result: The horn should sound.
Test the Tilt Sensor Alarm
38 Move a toggle switch, such as the engine idle
select switch.
Result: The alarm should sound at the platform
controls.
Test the Foot Switch
39 Push in the platform red Emergency Stop
button to the off position.
40 Pull out the red Emergency Stop button to the
on position and do not start the engine.
41 Press down the foot switch and attempt to start
the engine by moving the start toggle switch to
either side.
Result: The engine should not start.
42 Do not press down the foot switch and restart
the engine.
Result: The engine should start.
43 Do not press down the foot switch and test
each machine function.
Result: No functions should operate.
Test Machine Functions
44 Press down the foot switch.
45 Activate each function control handle, toggle
switch or thumb rocker switch.
Result: All functions should operate through a
full cycle.

Genie ZX-135/70 with Jib-Extend Specifications

General

Turntable Rotation	360° continuous
Platform Rotation	160°
Gradeability	45%
Maximum Platform Height	135 ft
Engine Power	74 hp
Fuel Type	Diesel
Stowed Height (ft)	10 ft
Max Working Height	141 ft
Platform Height	135 ft
Max Horizontal Reach	70 ft
Platform Capacity	600 lbs
Machine Width	8 ft 2 in
Stowed Height	10 ft
Drive Speed - Stowed	3.5 km/h
Jib Length	12 ft
Horizontal Reach	70 ft
Platform Capacity (lbs)	600 lbs
Drive Speed	3.5 km/h
Stowed Length	43 ft 2 in / 13.16 m
Stowed Width	8 ft 2 in
