Operator's Manual Third Edition • First Printing
Inspections
40 ZX-135/70 Part No. 1272823GT
92 Return to level ground and stow the boom.
93 With the boom fully stowed, drive the machine
onto a slope where the chassis angle is greater
than 4.5° along the Y-Axis (front to back).
Result: The machine should continue to drive.
94 Return to level ground and raise the secondary
boom to approximately 5° above horizontal.
95 Drive the machine onto a slope where the
chassis angle is greater than 4.5° along the
Y-Axis (front to back).
Result: The machine should stop once the
machine reaches 4.5° of chassis tilt and the
alarm should sound at the platform controls.
96 Lower the secondary boom to the stowed
position or drive in the opposite direction.
Result: The machine should drive.
97 Return to level ground and extend the jib boom
approximately 30 cm.
98 Drive the machine onto a slope where the
chassis angle is greater than 4.5° along the
Y-Axis (front to back).
Result: The machine should stop once the
machine reaches 4.5° of chassis tilt and the
alarm should sound at the platform controls.
99 Retract the jib boom to the stowed position or
drive in the opposite direction.
Result: The machine should drive.
100 Return to level ground and stow the jib boom.
101 With the boom fully stowed, drive the machine
onto a slope where the chassis angle is greater
than 4.5° along the X-Axis (side to side).
Result: The machine should continue to drive.
102 Return to level ground and raise the primary
boom to approximately 10° above horizontal.
103 Drive the machine onto a slope where the
chassis angle is greater than 4.5° along the
X-Axis (side to side).
Result: The machine should stop once the
machine reaches 4.5° of chassis tilt and the
alarm should sound at the platform controls.
104 Lower the primary boom to the stowed position
or drive in the opposite direction.
Result: The machine should drive.
105 Return to level ground and extend the primary
boom approximately 1.2 m.
106 Drive the machine onto a slope where the
chassis angle is greater than 4.5° along the
X-Axis (side to side).
Result: The machine should stop once the
machine reaches 4.5° of chassis tilt and the
alarm should sound at the platform controls.
107 Retract the primary boom to the stowed
position or drive in the opposite direction.
Result: The machine should drive.
108 Return to level ground and stow the boom.
