Genie ZX-135/70 with Jib-Extend User Manual

Third Edition • First Printing Operator's Manual
Inspections
Part No. 1272823GT ZX-135/70 43
Do Not Operate Unless:
 You learn and practice the principles of safe
machine operation contained in this operator’s
manual.
1 Avoid hazardous situations.
2 Always perform a pre-operation inspection.
3 Always perform function tests prior to use.
4 Inspect the workplace.
Know and understand the workplace
inspection before going on to the next
section.
5 Only use the machine as it was intended.
Workplace Inspection
Fundamentals
The workplace inspection helps the operator
determine if the workplace is suitable for safe
machine operation. It should be performed by the
operator prior to moving the machine to the
workplace.
It is the operator’s responsibility to read and
remember the workplace hazards, then watch for
and avoid them while moving, setting up and
operating the machine.
Workplace Inspection Checklist
Be aware of and avoid the following hazardous
situations:
 drop-offs or holes
 bumps, floor obstructions or debris
 sloped surfaces
 unstable or slippery surfaces
 overhead obstructions and high voltage
conductors
 hazardous locations
 inadequate surface support to withstand all
load forces imposed by the machine
 wind and weather conditions
 the presence of unauthorized personnel
 other possible unsafe conditions

Genie ZX-135/70 with Jib-Extend Specifications

General

Turntable Rotation	360° continuous
Platform Rotation	160°
Gradeability	45%
Maximum Platform Height	135 ft
Engine Power	74 hp
Fuel Type	Diesel
Stowed Height (ft)	10 ft
Max Working Height	141 ft
Platform Height	135 ft
Max Horizontal Reach	70 ft
Platform Capacity	600 lbs
Machine Width	8 ft 2 in
Stowed Height	10 ft
Drive Speed - Stowed	3.5 km/h
Jib Length	12 ft
Horizontal Reach	70 ft
Platform Capacity (lbs)	600 lbs
Drive Speed	3.5 km/h
Stowed Length	43 ft 2 in / 13.16 m
Stowed Width	8 ft 2 in
