Operator's Manual Third Edition • First Printing
Inspections
44 ZX-135/70 Part No. 1272823GT
Inspection for Decals with
Symbols
Use the pictures on the next page to verify that all
decals are legible and in place.
Below is a numerical list with quantities and
descriptions.
Part No. Decal Description Qty
27204 Arrow — Blue 2
27205 Arrow — Yellow 2
27206 Triangle — Blue 4
27207 Triangle — Yellow 4
28159 Label — Diesel 1
28174 Label — Power to Platform, 230V 2
28235 Label — Power to Platform, 115V 2
40434 Label — Lanyard Anchorage Point 8
44981 Label — Air Line to Platform (option) 2
52475 Label — Transport Tie Down 6
65278 Caution — No Step 6
72086 Label — Lifting Point 4
82247 Label — 107 dB 1
82472 Label — Crushing Hazard 2
82481 Label — Battery/Charger Safety 2
82487 Label — Read the Manual 2
97757 Label — Hydraulic Oil Level 1
97815 Label — Lower Mid-rail 1
114248 Label — Tip-over Hazard, Tilt Alarm 1
114249 Label — Tip-over Hazard, Tires 4
114251 Label — Explosion Hazard 1
Part No. Decal Description Qty
114252 Label — Tip-over Hazard, Limit Switches 2
133067 Label — Electrocution Hazard 3
133163 Label — Function Override
(Aircraft Protection Package)
1
133205 Label — Electrocution/Burn Hazard 2
160424 Cosmetic — ZX-135/70 1
160425 Cosmetic — ZX-135/70 1
160578 Label — Maximum Capacity, Wind &
Manual Force
1
160579 Label — Slope Rating 1
160682 Label — Wheel Load 4
160683 Label — Transport Diagram 2
161093 Label — Emergency Lowering
Instructions
1
219956 Label — Platform Overload 1
219958 Label — Tip-over, Crush Hazard 1
219974 Platform Control Panel 1
230985 Ground Control Panel 1
1255581 Cosmetic — Genie 2
1263542 Label — Compartment Access 5
1263544 Bypass Key Switch 1
1263545 Instructions — Bypass Key Switch 1
1271132 Cosmetic — Genie 2
1272242 Label — Machine Registration/
Owner Transfer
1
1279245 Label — Wheel Load 4
Shading indicates decal is hidden from view, i.e.
under covers
* These decals are model, option or configuration
specific.
To Next Page
