BLIZZARD 400-800 C ENC 25 532104 - Rev.A
Translation of the original instructions
ENGLISH
13 Advanced Programming
ADVANCED PROGRAMMING Default
PF
PRE-FLASHING:
OC = Sets a pre-flashing of 3 s on the LAMP output, before each
movement.
no = Pre-flashing on LAMP output disabled.
no
Ph
CLOSING PHOTOCELLS:
Sets the way in which the closing photocells operate
Y = Stop and reverse during opening when released.
no = Immediate reverse during opening.
no
OP
OPENING PHOTOCELLS:
Sets the way in which the opening photocells operate
Y = Immediate reverse during closing
no = Stop and reverse when released.
no
PO
PARTIAL OPENING:
This sets the partial opening width (OPEN B). It can be adjusted
from 00 to 99% of total opening.
50
t
CYCLE TIME-OUT:
Sets the maximum operating time of the gearmotor. Adjustable
from
20 s to 59 s, in steps of 1 s. And from 1.0 to 9.5 min (9 min
and 50 s), in steps of 10 s. Set a longer time for a complete opening
and closing cycle.
EG:
2.5=2 min. and 50 sec.
9.5
Sr
DECELERATION SPEED
Lo = standard deceleration speed.
Hi = high deceleration speed.
Lo
IP
REVERSE ON OBSTACLE MODE:
Y = Sets partial reverse after an obstacle has been detected by the
encoder or the safety edge.
no = Sets total reverse after an obstacle has been detected by
the encoder or safety edge.
no
OL
OUTPUT W.L.:
00 = LED, active during opening, when open and open in pause;
flashing during closing; off when gate closed.
01 = Courtesy light, active for the opening movement and for a
further 90 s.
00
O1
OUTPUT OUT
00 = Always active
01 = Fail-Safe test on SAFE input
05 = Gate open or open in pause
06 = Gate closed
07 = Gate moving
09 = Gate opening
10 = Gate closing
12 = Safety device active
13 = Traffic light control: output active when the gate is open and
open in pause; output disabled during pre-flashing, when moving
and when the gate is closed
14 = Timed output that can be activated by the second radio
channel (see the next function tl)
15 = Step by step controlled by the second radio channel
19 = Battery operation
00
tl
TIMING OF OUTPUT OUT:
Sets the activation time of the output OUT in timed mode that can
be activated by the second radio channel (
14). Adjustable from 01
min. to 99 min. in 1 second steps.
02
ADVANCED PROGRAMMING Default
Ob
INPUT OPEN B OPERATION
00 = OPEN B - partial opening command.
01 = SAFE - contact for opening edges.
02 = CLOSE - close command.
00
SP
INPUT STOP OPERATION
00 = STOP - automation stop command.
01 = SAFE - contact for closing edges.
00
St
AUTOMATION SYSTEM STATUS:
Y to save and exit from programming mode
no to exit from programming mode without saving
Press button
F to confirm; when finished, the display reverts to
the automation status display:
00 = Closed
01 = Open
02 = Stationary then opens
03 = Stationary then closes
04 = Paused
05 = Opening
06 = Closing
09 = Pre-flashing then opens
10 = Pre-flashing then closes
14 = Obstacle during opening
15 = Obstacle during closing
Y
