INSTALLATION GUIDE
Page 38
JP1 - JUMPER MUST BE INSTALLED ON PIN 2-3 = 4-20mA AND
JP2 - JUMPER MUST BE INSTALLED ON PIN 1-2 = STANDARD
IF A STATIC PRESSURE PROBE IS USED, JUMPER JP1 MUST BE SET TO
POSITION 2-3 (4-20mA). OTHERWISE, JUMPER JP1 MUST BE INSTALLED IN
POSITION 1-2 (STANDARD).
JP3 - JUMPER MUST BE INSTALLED ON PIN 1-2 = ID1 AND
JP4 - JUMPER MUST BE INSTALLED ON PIN 2-3 = 19200bps
JP1 - JUMPER MUST BE INSTALLED ON PIN 1-2 = ID1 AND
JP2 - JUMPER MUST BE INSTALLED ON PIN 1-2 = 19200bps
JP1 - JUMPER MUST BE INSTALLED ON PIN 2-3 = ID2 AND
JP2 - JUMPER MUST BE INSTALLED ON PIN 1-2 = 19200bps
JP1 - JUMPER MUST BE INSTALLED ON PIN 1-2 = ID1
JP1 - JUMPER MUST BE INSTALLED ON PIN 2-3 = ID2
REFER TO OPTI-GAIN 1 MANUAL FOR WIRING DETAILS.
REFER TO THE FEED BIN SCALE INSTALLATION MANUAL FOR MORE
DETAILS OF THE FEED BIN TRANSMITTER MODULE.
JP4 - JUMPER MUST BE INSTALLED ON PIN 1-2 = ID1 AND
JP4 - JUMPER MUST BE INSTALLED ON PIN 2-3 = ID2 FOR THE SECOND
MODULE, IF 2 MODULES ARE USED ON THE SAME PORT.
JP3 - JUMPER MUST BE INSTALLED ON PIN 2-3 = ID2 AND
JP4 - JUMPER MUST BE INSTALLED ON PIN 2-3 = 19200bps
MODULE AS ADJUSTMENT "PORT ID AND COMMUNICATION"
IN THE SETUP MENU.
FOR A LENGTH CABLE EXCEEDING 500’ (150M), INSTALLING A 120 OHMS
RESISTANCE ON THE A&B TERMINALS OF THE PORTS AT THE END OF THE
LOOP IS MANDATORY.
JP3 - JUMPER MUST BE INSTALLED ON PIN 1-2 = LEADING EDGE
JP4 - JUMPER MUST BE INSTALLED ON PIN 1-2 = LEADING EDGE
THE CURRENT SHALL NOT EXCEED 8A AT EACH OUTPUT.
