INSTALLATION GUIDE
Page 48
Typical Backup Thermostat Wiring
If the controller or a module fails, the backup thermostats will activate the dedicated fan
or heater as soon as temperature reaches the set point of the thermostat. The thermostat
must be accessible for adjustment and must be set at 3 to 5 degrees above the fan’s set
point or 3 to 5 degrees under the heater set point.
FIGURE NO. 9 Typical Backup Thermostat Wiring on ON/OFF Stage
L2
L1
RELAY BOARD
T15WD
1
2 P
FIGURE NO. 10 Typical Backup Thermostat Wiring on Variable Stage
L2
L1
VAR BOARD
OUT1
LINE
115/230
T15WD
1 2 P
L2/N
OUT
VAR
OUT
L2/N
OUT
VAR
OUT
L1
L2/N
OUT2
