Genius iTouch Series User Manual

INSTALLATION GUIDE
Page 52
Specifications
CONTROLLER
Storage temperature
-20°C to 55°C (-4°F to 131°F)
Operating temperature
0°C to 50°C (32°F to 122°F)
Humidity
90% maximum Non-condensing
NORMS
CSA (NRTL/C)
Weight (Small Enclosure)
12.4 kg (27.2 lb)
Size (Small Enclosure)
50cm x 40cm x 20cm
(19.7in x 15.8in x 7.9in)
Weight (Large Enclosure)
13.3 kg (29.2 lb)
Size (Large Enclosure)
61cm x 42cm x 24cm
(24in x 16.5in x 9.5in)
Protection index
IP 66
Warranty
2 years
POWER SUPPLY
Operational voltage range
90 to 250 VAC
Operational frequency range
45 to 65 Hz
Power supply circuit consumption (CPU
Board)
65 W maximum
INPUT BOARD (X1199)
PROBE INPUTS
Input measuring range
0 Ohm, open circuit
0-5000 mV
0-20 mA (PRB 15 and 16)
Maximum frequency for the water meter
(50% cycle)
4 Hz
Maximum wire length
150 m (500 feet)
Recommended wires
2 strands, shielded, AWG #22
12 VDC SOURCE (12VDC)
Maximum current allowed
100 mA
COMMUNICATIONS PORTS (P1, P2,
HUM)
Maximum wire length (2400 bps)
250 m (820 feet)
Maximum wire length (19200 bps)
2 m (6.5 feet)
Recommended wire
2 strands, twisted pair, low capacity, shielded,
AWG #22
ALARM RELAY (ALARM)
Maximum current
1 A at 30 VDC
Delay before switching
30 seconds (approximate)
Fuse
1A 250VAC
