Genius iTouch Series - Page 53

INSTALLATION GUIDE
Page 53
RELAY BOARD (X1184 or X1414)
OUTPUT RELAYS
Maximum Power
20A @ 240VAC
Maximum Current
2HP @ 240VAC, 1HP @ 120VAC
Caution Notice
These relays are rated by UL and CSA at 20A
or 2HP. However, for outputs requiring
frequent activation (ex : minimum ventilation
fans working on a timer) it is recommended
not to use more than 1 HP per relay (at 250
VAC)
POT BOARD (X1205)
INLET POTENTIOMETER
(POT 1 TO POT 8)
Inlet potentiometer
0-10K ohms
Maximum wire length
150 m (500 feet)
Recommended wire
3 strands, shielded, AWG #22
OUTPUT BOARD (X1201)
COMMUNICATIONS PORTS (P3 - P4)
Maximum wire length (2400 bps)
250 m (820 feet)
Maximum wire length (19200 bps)
2 m (6.5 feet)
Recommended wire
2 strands, twisted pair, low capacity, shielded,
AWG #22
SOURCE 12 VDC (12VDC)
Maximum current allowed
100 mA
0-10V OUTPUT
(0-10V OUTPUT 1 AND 0-10V OUTPUT 2)
Output
0-10Volts, 2% precision
Maximum load
10mA
Maximum wire length
30 m (100 feet)
Recommended wire
2 strands, shielded, AWG #22
VAR. BOARD (X1204 or X1418)
TRIAC OUTPUT
Maximum Allowable Current (Fuse value)
8A, 120 / 208 / 240VAC
Recommended maximum current for
incandescent lighting
7A, 120 / 208 / 240VAC
Recommended maximum current for fans
6A, 120 / 208 / 240VAC
Maximum wire length
(Var. Communication)
200 m (650 feet)
Recommended wire
2 strands, twisted pair, low
capacity,(Capacitance between conductors @
1Khz = 24pF/ft), shielded, AWG #22
