Genius iTouch Series User Manual

INSTALLATION GUIDE
Page 54
8 COMM. PORT (X1276)
COMMUNICATIONS PORT (P9-P16)
Maximum wire length (2400 bps)
820 feet (250m)
Maximum wire length (19200 bps)
6.5 feet (2m)
Recommended wire
2 strands, twisted pair, low capacity,
shielded, AWG #22
SOURCE 12 VDC (12VDC)
Maximum current allowed
100mA
8-INPUT MGCB BOARD (X1399)
PROBE INPUTS (PRB1-PRB8)
Input measuring range
0 Ohm, open circuit
0-5000 mV
0-20 mA (PRB 7 and 8)
Maximum frequency for the water meter
(50% cycle)
4 Hz
Maximum wire length
150 m (500 feet)
Recommended wires
2 strands, shielded, AWG #22
SOURCE 12 VDC (12VDC)
Maximum current allowed
100mA
8-INPUT BOARD (X1200)
PROBE INPUTS (PRB1-PRB8)
Input measuring range
0 Ohm, open circuit
0-5000 mV
0-20 mA (PRB 7 and 8)
Maximum frequency for the water meter
(50% cycle)
4 Hz
Maximum wire length
150 m (500 feet)
Recommended wires
2 strands, shielded, AWG #22
SOURCE 12 VDC (12VDC)
Maximum current allowed
100mA
Important Notice:
- It is important to have a backup system in case of a system failure.
- Low-voltage and high-voltage wires must be passed through different conduits at
least 1 foot (30 cm) apart. If low-voltage and high-voltage conduits must be
crossed, the crossing must be at a 90-degree angle.
- All wiring must be made by a certified electrician and conform to local electrical
regulations.
