1. Plug the supplied AC power cord
(A) into the charger connector.
Always keep the power cord with
the GenZe 2.0. Always connect the
charger to a GROUNDED outlet.
2. If the battery is charged outside, it
should be plugged into a Ground
Fault Current Interrupter (GFCI)
outlet. A portable GFCI cord is
available as an accessory from
your GenZe 2.0 authorized dealer.
3. Remove and store the AC power
cord when the green LED (A) is
solid.
NOTE: After unplugging the
battery, you must wait for
approximately 30 seconds before
turning on the GenZe 2.0. The
charger requires this time to
shut down. Pressing the Start
Button before this time has
elapsed will not turn on the
GenZe 2.0.
