IF the is THEN
flashing green a code-only position is available.
green a fixed RTK position is available.
Power LED off battery is not connected, flat or the GNSS receiver is
switched off.
green power is 20% - 100%.
red power is 5% - 20%. The remaining time for which
enough power is available depends on the type of
measurement, the temperature and the age of the
battery.
fast flashing red power is low (<5%).
Storage LED off no microSD card is inserted.
green microSD card is inserted but no raw data is being
logged.
flashing green raw data is being logged.
flashing red raw data is being logged but only 5% memory left.
red microSD card is full, no raw data is being logged or
no microSD card is inserted but the GNSS receiver is
configured to log raw data.
18 User Interface
