2. Remove the cover from the battery compartment.
3. With the battery contacts facing upwards, slide the battery into the cover of the bat-
tery compartment.
4. Push the battery downwards so that it locks into position.
5. Insert the cover of the battery compartment into the compartment and push the
slide fastener in the direction of the arrow with the close-lock symbol.
6. To remove a battery, push the slide fastener of the battery compartment in the dir-
ection of the arrow with the open-lock symbol and remove the cover.
7. Push the battery slightly upwards and at the same time pull out the bottom part of
the battery. This releases the battery from its fixed position.
8. Remove the battery.
4.6 Insert a microSD Card
•
Keep the card dry.
•
Use it only within the specified temperature range.
•
Do not bend the card.
•
Protect the card from direct impacts.
Failure to follow these instructions could result in data loss and/or permanent damage to the
card.
☞
Removing the microSD card while the GNSS receiver is turned on can cause loss of
data. Only remove the microSD card or unplug connecting cables when the GNSS
receiver is switched off.
☞
The microSD card is inserted into a slot inside the battery compartment of the GNSS
receiver.
1. Push the slide fastener of the battery compartment in the direction of the arrow with
the open-lock symbol.
2. Remove the cover from the battery compartment.
3. Press the latch of the SIM/microSD card cover and remove the cover.
4. Slide the microSD card with the logo facing upwards firmly into the slot until it clicks
into position.
☞
☞
Insert a microSD card
step-by-step
24 Operation
