Menu Zeta125/ Zeta125s | 49
EN
Calibration
5. Measure the height difference between the target and the reference
point. Write down the value.
6. Subtract the values for the two height differences.
Over a distance 60 m, the result must be less than 3 mm.
7. If the value is larger, repeat step 2. to 6. to make sure that the meas-
uring points are correct.
8. If the failure is reproducible, calibrate the laser. Run through the steps
in the next table.
Step Description
The calibration has to be done by a qualified authority.
Place the pipe laser on a horizontally aligned base.
1.
Press to select MAIN AXIS.
WAIT is displayed.
2. Wait until SET is displayed.
Step Description
GeoMax_Zeta125_Zeta125s_UM_v1.0.0_en.fm Page 49 Friday, November 28, 2014 9:23 AM
