GeoMax Zeta125 - 7 Technical Data; Technical Data

Zeta125/ Zeta125s | 68Technical Data
EN
7 Technical Data
7.1 Technical Data
Accuracy At 20 °C: ±10" / ± 4.8 mm at 100 m
Range
Instrument
dimensions
Weight 2.1 kg
Power supply
Levelling range: -15% / +45%
Grade range: Direction: ±10°
Grade: –10% / +40%
Operation range: > 200 m
Length [mm] Height [mm] Thickness [mm]
305 105 113
Internal power supply: Li-Ion battery, controller charged
Internal supply voltage: • 230 V/110 V AC power supply with charger
• Nominal voltage 24 V DC supply with acces-
sories cable
