Advanced Applications
129
7
7.2 Backing Up and Restoring Settings
With the IP Device Utility included on the Software CD, you can back up the configurations in
the GV-IP Speed Dome, and restore the backup data to the current unit or import it to another
unit.
Note: The settings for PTZ movements (Preset, Sequence, Cruise, Auto Pan and Tour) of
the GV-IP Speed Dome can not be exported and imported.
To back up the settings:
1. Run IP Device Utility and locate the desired GV-IP Speed Dome. See Steps 1-3 in 7.1.2
Using the IP Device Utility.
2. Double-click the GV-IP Speed Dome in the list. Figure 7-4 appears.
3. Click the Export Settings tab. This dialog box appears.
Figure 7-6
4. Click the Browse button to assign a file path.
5. Type Password, and click Export Settings to save the backup file.
To Next Page
