Chapter 8 CMS Configurations
This section introduces the related settings to enable connecting to the GV-Video Server in
the central monitoring stations Center V2, VSM and Dispatch Server.
8.1 Center V2
The Center V2 can monitor and manage the cameras and I/O devices connected to the
GV-Video Server.
GV-Video Server
GV-Video Server
TCP/ IP
X 2
X 2
Center V2
Video Data
X 2
X 2
Text Data
Figure 8-1
¾ To set the appropriate port connecting to the GV-Video Server, click the Preference
Settings button, select System Configure, click the Network tab, and check Accept
connections from GV-Compact DVR, Video Server & IP Cam. Keep the default
port 5551 for the Port 2 option, or modify it to match the Center V2 port on the GV-
Video Server.
Figure 8-2
98
