1.6.2.2 GV-VS02A
Figure 1-8
No. Name Function
1 USB Port 2 USB ports for installing portable storage devices.
2 Terminal Block
The connectors for digital input, relay output, PTZ camera,
Wiegand device and GPS module control. See Chapter 9 Auxiliary
Device Connectors.
3 Ethernet Port
A plug for inserting an Ethernet cable to build the network
connection.
4 Power In A plug for power input.
5 Power Out A plug for power output.
