1.6.2 Rear View
1.6.2.1 GV-VS02
Figure 1-7
No. Name Function
1 USB Port 2 USB ports for installing portable storage devices.
2 Terminal Block
The connectors for digital input, relay output, PTZ camera, Wiegand
device and GPS module control. See Chapter 9 Auxiliary Device
Connectors.
Note the GPS function is only available on GV-VS02 (Hardware
Version 2.0).
3 Ethernet Port
A plug for inserting an Ethernet cable to build the network
connection.
4 Power In A plug for power input.
5 Power Out A plug for power output.
