Gerber XLp - Configuration; Gerber Device Configuration

18XLp Installation & Configuration, June 2010
Gerber Device Configuration
• On the Start menu, point to Control Panel.
• Double click the Gerber Device icon.
• The Gerber Device Configuration window will
appear.
• Click the Plotter tab (only on AccuMark systems).
• In the Type box, select XLP USB PLOTTER (XLP-
PLOTTER).
• In the Settings box COM-W will appear.
• Click Apply.
• Click OK.
