Gerber XLp - Plot Tab

34XLp Installation & Configuration, June 2010
Service Level : Plot Tab
To get additional spacing
between jobs.
Set the plotting speed to
a lower value.
Make sure no one changes
the values of X and Y
scaling. They have to be
set at 1 and NOTHING
ELSE.
Allows to switch to uni-
directional printing (slower
but better quality)
