Appendix A
Specifications
NOTE: Specifications are subject to change without any prior notice.
Parts Specifications
CPU Whiskey Lake U Platform
- Intel® Core™ i5-8265U, 1.6GHz up to 3.9GHz, 6M cache
- Intel® Core™ i5-8365U, 1.6GHz up to 4.1GHz, 6M cache
- Intel® Core™ i7-8565U, 1.8GHz up to 4.6GHz, 8M cache
- Intel® Core™ i7-8665U, 1.9GHz up to 4.8GHz, 8M cache
BIOS Insyde, Flash EEPROM, UEFI, supporting TPM, vPro, NIST,
Absolute DDS, HDD Security Erasure, BIOS self-diagnostic,
Device Guard & Credential Guard, MAC Pass through, ACPI,
AMT12, and WMI
RAM 8/16GB DDR4 SO-DIMM, 2400MHz
Video Controller UMA - Intel® UHD Graphics 620
Display
Panel
11.6-inch (16:9) TFT LCD, FHD 1920x1080, sunlight readable,
800 Nits maximum brightness, anti-glare
Touchscreen Capacitive, multi-touch,10 points
Audio Features High Definition audio
Speaker 1.5 W x 1
Microphone
Integrated microphone
Hard disk drive 256GB/512GB/1TB SSD (Solid-State Drive)
I/O
ports
Standard USB 3.1 Gen 2, combo audio (4-pole TRRS 3.5mm type), HDMI,
Docking
Optional One of the below on the top side:
RS-232 / RJ45 / USB 2.0 / barcode reader
One of the below at the rear:
Smart card reader / NFC/RFID reader + RJ45 / fingerprint
scanner
LAN (option) 10/100/1000 Mbps Ethernet
