9
Ref
Component Description
The near infrared (IR) imaging capability allows you to
use Windows Hello face authentication.
Camera lens
(optional)
Allows you to use the camera function. When the
camera lens is in use, the indicator beside it lights up.
Light sensor
Senses the ambient light for automatic adjustments of
the display backlight.
Power button
Turns the power on or off. (The default “off” state is
“Sleep mode.”)
P1 button Trigger
Serves as the trigger button for the barcode
scanner if your model has the option.
Camera
Starts the G-Camera application and serves
as the shutter release button.
This is the default function for models
without the barcode scanner.
P2 button Opens or closes the OSD Control Panel.
When pressed longer:
Serves as the Ctrl+Alt+Del keyboard keys.
Plus button Increases the sound volume.
Minus button Decreases the sound volume.
Touchscreen Displays and receives information for the Tablet PC.
Speaker Sends out sound and voice from your Tablet PC.
Indicators
Power
Lights blue when the power is on.
Blinks blue when the system is in Sleep mode.
Battery Lights amber when the battery is being charged.
Lights green when battery charging is completed.
Blinks green to indicate the battery’s built-in high
temperature protection mechanism is activated.
CAUTION: Do not remove the battery during this period.
Blinks red (once per second) when the battery’s
capacity is below 10%.
