12
Ref
Component Description
Power
connector
Connects the AC adapter.
Select models have one of the below components.
a
Fingerprint
scanner
Serves as the fingerprint verification, preventing
unauthorized access to your Tablet PC.
b
RFID reader Reads data from RFID tags.
Left-Side Components
For covers with an arrowhead icon, push the cover toward one side to unlock
and the other side to lock. The arrowhead points to the side for unlocking.
Ref
Component Description
USB-C
Thunderbolt™
port
Connects to devices that support Thunderbolt or
USB-C connection.
Micro-SIM card
slot (optional)
Accepts a micro-SIM card for models having the
WWAN module.
NOTE: The slot still exists but cannot be used for models
without the WWAN module.
USB 3.2 Gen 2
port
Connects a USB device.
Combo audio
connector
Connects a set of headphones or external speakers
with amplifier.
Supports a headset microphone with 4-pole TRRS
3.5mm jack.
