14
Ref
Component Description
c
MicroSD card slot
Accepts a microSD card for removable storage
media.
d
USB 2.0 port Connects a USB device.
e
Barcode scanner
lens
Scans and reads barcodes.
f
RJ45 connector Connects the LAN cable.
Bottom Components
Ref
Component Description
Antenna pass-
through (optional)
Connects to the docking station for using
external GPS /WWAN/WLAN antenna.
NOTE: The “WLAN” function can be changed to
the “WWAN Aux” function. Use G-Manager to
change the function if needed.
Docking connector
Connects to the docking station (available as an
option).
