PROCESS
Changing parameters
Normally the preset parameter settings of the installed programs are used, but in special
cases it may be necessary to adjust certain parameters for matching to a specic wash
process. Information about the parameters that can be changed and their limit values can
be found under heading “A- or P-parameters” in Chapter 4 of the service manual.
Printing out a program for a machine with printer (option)
An example of a program printout is shown below. In the example, program P02 OP-D,
programmed on menu selection button 2 is used.
PH360-RINSE 2
00:14:46 55.5
----------------------------
PH440-Final rinse
00:16:03 53.5
00:19:53 80.1
DOS START
00:20:15 81.5
DOS.STOP
DOS AMOUNT 230ml
00:21:26 90.0
CONDUCTIVITY 2 uS/cm
00:21:27 90.1
DISINF START
00:22:27 92.3
DISINF STOP
00:22:45 91.7
----------------------------
PH900-DRYING
00:22:46 91.7
00:34:27 80.8
----------------------------
PH1000-ENDING
00:34:49 81.1
----------------------------
SIGNATURE: .........
PROGRAM:P2 OP-D
DATE:02/05/2006
PROCESS START:13:44:46
MACHINE NAME:88-5
MACHINE NO:2
CYCLE COUNTER:53
PARAMETER
WASH 1 DOS TEMP 35.0C
WASH 1 DOS 1 200
WASH 1 Temp. 60.0
WASH 1 time 00:03:00
FINAL R DOS TEMP 80.0
FINAL R DOS 3 00:00:21
DISINF TIME 00:01:00
DISINF TEMP 90.0
DRYING TEMP 90.0
DRYING TIME 00:18:00
SIGNALS
A107 TEMP INDEP. CHAMB
----------------------------
PROGTIME A107
----------------------------
PH1-START
00:00:00 30.8
00:00:40 30.7
----------------------------
PH220-PRE RINSE 1
00:01:10 31.0
----------------------------
PH25-WASHING
00:02:51 18.1
00:04:52 35.2
DOS START
00:05:53 39.9
DOS.STOP
DOS AMOUNT 202ml
00:09:17 60.0
00:10:17 60.8
00:11:17 61.9
00:12:17 61.5
----------------------------
PH330-RINSE 1
00:13:29 61.5
----------------------------
