Control system
The machine has an electronic controller which can hold up to 64 programs, 16 of which
can be started (activated). You can choose six of these programs with the program selec-
tion buttons. To choose the others, use the menu buttons; see under Operating instruc-
tions. The machine comes with a number of standard programs in the control system
(see the separate program sheet). Contact your reseller for customized programs.
Programming may only be done by authorized personnel.
Door function
The machine has double vertical sliding doors.
Both doors can be motorized for automatic opening and closing. The doors have effec-
tive crush protection. When it is activated, they reverse.
The doors of the machine have a system of interlocks to ensure that only one door can
be opened at a time. This means that the clean-side door must be closed and locked by
pressing the W button before the dirty-side door can be opened.
When you press V, the door is locked and a yellow lamp ashes for about 5 seconds.
If V is pressed again during this “cancel time”, the dirty-side door is unlocked and the
door can be opened manually or alternatively it opens automatically.
In standby mode, the door can be opened and closed with U by pressing the button for
10 seconds.
When V (on the soiled side) is pressed, the door is closed and locked, the yellow lamp
ashes and the program starts.
When the program is complete, a green lamp lights up on both sides and the clean-side door
opens automatically. When the door is fully open the green lamp goes out on both sides.
The clean-side door must be closed and locked by pressing the W button before the
soiled-side door opens automatically.
V398
Soiled sideClean side
