Slimdrive EMD / -F / -F-IS / Invers
5
General safety precautions
Term Statement
Push&Go When the door is manually pushed out of the closed position with an activated Push
& Go function in the AUTOMATIC operating mode, the door opens automatically as
soon as a specic adjustable angle is exceeded.
Safety sensor open (SIO) Presence detector (e.g. active infrared light sensor) for protecting the swing area of
the door in the opening direction. As a rule the sensor is located on the hinge side of
the door on the door leaf.
Safety sensor close (SIS) Presence detector (e.g. active infrared light sensor) for protecting the swing area of
the door in the closing direction. As a rule the sensor is located on the opposite hinge
side of the door leaf.
Emergency stop Self locking switch which can trigger immediate stopping of the door drive in the case
of danger. The drive remains in its current position until the user releases the emer-
gency stop switch again, thus terminating the emergency stop situation.
Door closing sequence selec-
tor
Electrical door closing sequence selector
In normal operation of double-leaf door drives, the closing sequence of the door
leaves is controlled by the control units of the door drives, with the xed leaf be-
ing closed rst. The active leaf remains in the open position until the xed leaf has
reached the closed position, then the active leaf begins to close.
Integrated door closing sequence selector (-IS)
In the event of a power failure, the closing sequence is controlled mechanically on
double-leaf door systems with Slimdrive EMD-F-IS. The door leaves are closed by
means of the power storage of the drives, with the active leaf being kept open by the
integrated mechanical door closing sequence selector at an opening angle of approxi-
mately 30° before the closing position is reached. When the xed leaf has reached the
closed position, it releases the active leaf by means of the mechanical elements of the
door closing sequence selector so that it can also close completely.
Electrical door opener Open-circuit door opener
Available as AC or DC door opener version. When the door drive is actuated, the door
opener is activated by the control unit of the door drive provided the door is in the
closed position. The door opener remains activated until the door has left the closed
position.
Closed current opener
DC door opener version. The door opener is switched o when the door drive is acti-
vated provided the door is in the closed position. The door opener remains switched
o until the door has left the closed position.
Lock feedback The lock feedback function is a contact integrated in the door catch that is activated
when the door is locked mechanically by the tie bolt of the door lock. It signals to the
control unit that the door is locked mechanically and can therefore not be opened by
the door drive. In this case the control unit ignores the control commands of all the
contactors.
Reset Button for restarting the drive after the operating voltage has been switched on or
after a re alarm has been terminated. When the button is pressed, the self-retention
integrated in the drive is activated, causing the drive to be activated.
Latching function When the door is closed in a de-energised state, the door leaf is impeded by the lock
latch of the door opener. To make sure the door can pass the lock latch safely during
closing, an integrated limit switch is actuated in the drive once a specic angle has
been reached, reducing the braking strength. The door accelerates and closes into the
lock at increased speed. In an energised state, this function is regulated by the drive
control unit.
1)
The "SHOP CLOSING-TIME" operating mode can only be selected using the optional
mechanical programme switch.
