Slimdrive EMD / -F / -F-IS / Invers
4
General safety precautions
1 General safety precautions
à Carefully read and abide by this user manual before commissioning the door. In addition, always observe the
following safety precautions:
à Operating, maintenance and repair conditions specied by GEZE must be observed.
à The commissioning, prescribed installation, maintenance and repair work must be performed by properly
trained personnel authorised by GEZE.
à GEZE shall assume no liability for damage caused by unauthorised changes to the system.
à The owner is responsible for safe operation of the system. If safety equipment is misaligned, thus preventing
it from fullling its intended purpose, further operation is not permissible. The service technician must be
informed without delay.
à GEZE is not liable if products from other manufacturers are used with GEZE equipment. Furthermore, only
original GEZE parts may be used for repair and maintenance work.
à The connection to the power supply must be made by a professional electrician.
X
The power connection and safety earth conductor test must be carried out in accordance with
DIN VDE 0100-610.
à Use a customer-accessible 10-A overload cut-out that disconnects the system from the power supply as the
line-side disconnecting device.
à Attach safety stickers to glass door leaves.
à Protect the programme switch against unauthorised access.
à In compliance with Machine Directive 2006/42/EC, a risk analysis must be performed and the door system
identied in accordance with CE Identication Directive 93/68/EEC before the door system is commissioned.
à Observe the latest versions of guidelines, standards and country-specic regulations, in particular:
à ASR A1.7 "Guidelines for doors and gates"
à DIN 18650 "Building hardware - Powered pedestrian doors"
à DIN VDE 0100-610 "Erection of low-voltage installations"
à DIN EN 60335-2-103 "Safety of electrical devices for home use and similar purposes; special requirements
for drives for gates, doors and windows"
à Accident-prevention regulations, especially BGV A1 "General regulations" and BGV A2 "Electrical systems
and equipment"
1.1 Terms
Term Statement
Hinge side The side of the door where the hinges from which the door leaf is suspended are
located. Usually that side of the door located in the opening direction.
Opposite hinge side The side of the door that lies opposite the hinge side. Usually that side of the door
located in the closing direction.
Active leaf The main leaf of a double-leaf door. The active leaf must open as the rst door leaf and
close as the last door leaf when the door is used.
Fixed leaf The secondary leaf of a double-leaf door. When the door is used, the xed leaf may
not open until the active leaf has left the closing position and must close again as the
rst door leaf.
Inside contactor (KI) Button, switch or movement detector for controlling the door drive.
The contactor is located within the room enclosed by the door.
Control function in the AUTOMATIC and SHOP CLOSING-TIME operating modes
1)
.
The contactor does not have any function in the NIGHT/OFF operating mode.
Outside contactor (KA) Button, switch or movement detector for controlling the door drive.
The contactor is located outside the room enclosed by the door.
Control function in the AUTOMATIC operating mode. The contactor does not have any
function in the SHOP CLOSING-TIME
1)
and NIGHT/OFF operating modes.
Contactor
authorised (KB)
Access control function (for example key-operated switch or card reader) used by
authorised persons to control the door drive.
The control function is active in the "AUTOMATIC", "SHOP CLOSING-TIME
1)
” and
"NIGHT/OFF" operating modes.
Contactor with current im-
pulse function
Button for opening and closing the door. Control function only in the AUTOMATIC and
SHOP CLOSING-TIME
1)
operating modes. The door is opened automatically when the
button is rst pressed and closed again automatically when the button is pressed the
second time. The function can be activated during commissioning by setting param-
eters using the display programme switch, ST 220 or GEZEconnects. If the contactor is
connected to the xed leaf control system by means of the "current impulse" function,
both door leaves open when activated, even when the xed leaf control system is
deactivated.
