7
VH-2600
Airway set Point: 31 - 40
°
C (default 39
℃
)
Chamber set Point: 31-40°C(default 37℃, limited to Airway set Point -5 to +2℃)
VH-2600A
 Heater Wire Circuit
 Invasive mode
Airway Set Point:36~40 (default:40°C)
Chamber Set Point:36~40 ( default :37°C)ver1.00
Chamber Set Point:34~40 ( default :37°C)ver1.01
 Non –Invasive
Airway Set Point:31~35 (defaul:34°C)
Chamber Set Point:31~35 (default :31°C)
 Non-Heater Wire Circuit:
Invasive mode: Airway Set Point:36~38 (default:37°C)
(chamber temperature limited to 66 °C)
Non –Invasive: Airway Set Point:30~32 (default :31°C)
(chamber temperature limited to 66 °C)
2.3.2. Alarm Parameters:
Heater Wire Circuit:
- High Airway Alarm: An immediate, audible alarm at a displayed temperature of 41°C or if the airway
temperature exceeds 42°C.
- Low Airway Alarm: An audible alarm between 10 minutes @29.5°C, and 60 minutes @34.5°C
- High Humidity Alarm: An audible alarm if the humidity temperature exceeds 41°C.
- Low Humidity Alarm: An audible alarm between 10 minutes @26°C.
Non-Heater Wire Circuit:
- High Airway Alarm: An audible alarm if temperature exceeds 41°C
- Low Airway Alarm: An audible alarm if temperature descends @29.5°C in invasive mode, or @26°C
non-invasive mode
- High Humidity Alarm: Light will twinkle but no alarm if the humidity temperature exceeds 66°C.
- Low Humidity Alarm: An audible alarm between 10 minutes @26°C.
2.4. Performance
Recommended ambient temperature range: 18-26°C.
Recommended Flow Range:
Invasive Mode: up to 60 L/min, Noninvasive Mode : up to 120 L/min.
Refer to breathing circuit specifications for minimum flow.
Humidity Performance: Invasive Mode: > 33 mg/L, Noninvasive Mode: > 10 mg/L.
Warm-up time: Less than 30 minutes.
Maximum Operating Pressure: 20 kPa, gas leakage at max. pressure < 50 mL/minute.
