Installation Manual Series CF (excluding encapsulated screw compressors) 23042013 Rev. A / May 2007 56 of 60
CF180R Technical data (Page 1 of 2)
Dimensions: 987 mm x 626 mm x 535 mm (LxWxH)
Weight: 725 kg
Permissible areas of operation:
min max
Speed of male rotor 725 1/min 3723 1/min
Suction pressure 0,62 bar(abs)
atmospheric
pressure
Discharge pressure 6 bar(abs) * 16 bar(abs)
Discharge temperature 110°C
Belt drive permitted YES
* without additional oil pump
