PUSHTOOPEN
©Ghost Controls
®
2020
PUSHTOOPEN: GATE SWINGS TO OPEN OUTSIDE PROPERTY
The dimensions and step-by-step instructions that follow are for mounting the GHOST CONTROLS
®
Gate Operator
PUSH-TO-OPEN installation system to a standard gate that swings away from your property. You will need to make sure
you purchase the Push-To-Open Bracket Kit (AXPO) before you start installing.
FOR PULLTOOPEN APPLICATIONS, PLEASE SEE PULLTOOPEN APPLICATION ON “PULL TO OPEN
INSTALLATION” ON PAGE 18.
STEP 1. Establish and mark the horizontal center lines of the gate and the post for proper alignment
of gate brackets.
NOTE
This center point will be used
for mounting the post bracket
in STEP 4.
PUSH TO OPEN INSTALLATION
OPERATOR ARM INSTALLATION
NOTE
Wheels cannot be used with
any Ghost Controls
®
gate
opener system!
For gates weighing over 200
lbs. ball bearing hinges are
recommended.
Operator is not for use on
solid panel privacy gates.
PUSHTOOPEN: GATE SWINGS TO OPEN OUTSIDE PROPE
