49 FT-M1211A
4M05674 FRAME
ID Reference Qty Descri ption
1 3S01569 1 Cross support beam
2 2S04676 1 Right side frame
3 2S04675 1 Left side frame
4 2T06882 1 Left leg assembly
5 2T06883 1 Right leg assembly
6 2S04692 2 Cross brace
7 2T06956 2 Longitudinal cross brace
8 2T06891 1 Template boomerang guard
9 2T06935 2 Back frame brace
10 12-0393 2 Foot bolt M16x100xD15
11 12-0394 2 Base PA D80 D15
12 2T07003 4 Reservoir bracket
13 2T07013 1 Jet deflector
14 09-0147A 2 Tank left
15 09-0165A 1 Tank right
