Giabau FT-MAXI - 4 M05631 Shuttle LU450; 4 M05646 Shuttle LU450 - Straps; 4 M05644 Shuttle Lu450 Kit 09-0146 A

83 FT-M1211A
4M05631 SHUTTLE LU450
4M05644 SHUTTLE LU450
KIT 09-0146A
4M05646 SHUTTLE LU450 - STRAPS
ID Reference Qty Descri pti on
11 2C01902 4 Felt strap stapled W60 - L4100
ID Reference Qty Descr i ption
5 14-0819 1 Strut cylinder D25-C500
6 14-0429 2 Elbow connector auto M5_4-6
ID Refer ence Q ty Descripti on
1 2T06897 1 Shuttle base LU0450
2 2C01901 2 Shuttle slide LU615
3 3S01567 1 Shuttle nose U
4 2D01847 1 Axle 6 Pans-17 W32-D8L19-M6
5 14-0819 1 Cylinder D25-C500
6 14-0429 2 Link auto M5-4-6
7 3D00856 1 Unidirectional roller W=435
8 3D00857 1 Unidirectional roller W=365
9 10-1222 1 Roller 20x1.5 W411/406 Axle 08xM5
10 10-0356 1 Roller 40x1.5 W445/435 Axle 12xM8
11 2C01902 4 Stapeld felt belt LA60-LG4100
